NVIDIA QUADRO GV100

  • GPU Architecture: Volta
  • CUDA core: 5120
  • Memory Capacity: 32GB HBM2
  • Memory Bandwidth: UP to 870 GB/s
  • Single Precision: 14.8 TFLOPs
  • Double Precision: 7.4 TFLOPs
  • Deep Learning Performance: 118.5 TFLOPS

About

The NVIDIA® Quadro® GV100 reinvents the workstation to meet the demands of AI-enhanced design and visualization workflows. It’s powered by NVIDIA Volta, delivering extreme memory capacity, scalability, and performance that designers, architects, and scientists need to create, build, and solve the impossible.

Specification

Specifications
GPU Architecture
Volta
CUDA Cores
5120
GPU Memory
32GB HBM2
Memory Interface
4096-bit
Memory Bandwidth
UP to 870 GB/s
FP64 Performance
7.4 TFLOPs
FP32 Performance
14.8 TFLOPs
FP16 Performance
29.6 TFLOPS
Integer Operation (INT8) Performance
59.3 TFLOPS
Deep Learning Performance
118.5 TFLOPS
Max Power Consumption
250 W
Display Connectors
4x DP 1.4
DP 1.4/1.3 Resolution
4x 4096x2160 @ 120Hz
4x 5120x2880 @ 60Hz
2x 7680x4320 @ 60Hz
1x 7680x4320 @120Hz
Thermal Solution
Active
Form Factor
4.4” H x 10.5” L Dual Slot,Full Height
Graphics APIs
Shader Model 5.1, OpenGL 4.51, DirectX 12.02, Vulkan 1.01
Compute APIs
CUDA, DirectCompute, OpenCL™
